Phoenix Contact 1881503 PCB pin housing 8 pin 2.5 mm pitch green solder

Phoenix Contact manufactures an 8-pin housing PCB with a contact spacing of 2.50 mm, identified by part number 1881503. This industrial product is typically used for electrical connections on printed circuit boards and is packaged in units of 50. Designed for reliability in various applications, these housings are suited for industrial environments requiring robust connection solutions.

Body Style	Plug, horizontal mount
Pitch	2.5mm
No of Ways Per Row	8
No. of Rows	1
Current Rating	4A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/contact	N/A
Connection	Print
Connector model	Other
Connector orientation	Parallel (to the PCB)
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Pin
Diameter connection pin	1.2mm
Dim	(L x W x H) 10.10 x 21.90 x 11.90 mm
Height	11.90mm
Housing Colour	Green
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	10.10mm
Length pin	3.8mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	MC 0,5/ 8-G-2,5
Modular spacing connections	2.5mm
Modular spacing contacts	2.5mm
Nominal Voltage	160V
Number of plug-in contact rows	1
Number of Poles	8
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	4A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	MC
Suitable for PCB thickness	N/Amm
Total number of pins	8
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	21.90mm
