Phoenix Contact 1844252 mini combicon housing 6 pins 3.50mm low profile

Image Representative of Range

Phoenix Contact 1844252 mini combicon housing 6 pins 3.50mm low profile

Phoenix Contact
Order Code:

06-2138

Brand: Phoenix Contact MPN: 1844252 EAN-13: 2050000437717
Qty Unit Price (Ex VAT)
5+ £0.945
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
60 in stock, despatched in 4 working days

The Phoenix Contact pin housing PCB, model number 1844252, features six pins with a contact spacing of 3.50 mm. It supports a nominal current of 8 A, making it suitable for various electrical connections and PCB applications. This component is commonly used in connectors, clamps, and basic units in electronic circuits.
A 17.50mm
Connection Print
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Plug, horizontal mount
Contact Material Tin plated
CS 3.50mm
Dim (L x W x H) 9.20 x 22.40 x 10.65 mm
Factory colour Green
Height 10.65mm
Industrial packaging Yes
Length 9.20mm
Misc Attribute MC 1,5/ 6-G-3,5
Nominal Current 8A
Nominal current - rounded value 8A
Nominal current (details) 8A
Nominal Voltage 160V
Number of Rows 1
Pins per row 6
Series MC
Total number of pins 6
Type Pin housing PCB
Width 22.40mm
