Phoenix Contact 1843622 MINI COMBICON housing 4 pins 3.50 mm spacing

Phoenix Contact manufactures a pin housing PCB connector, model number 1843622, with four pins and a contact spacing of 3.50 mm. This connector is designed for handling a nominal current of 8 A, making it ideal for various electronic circuit board applications. It is commonly used in securing and connecting components in electronic devices and equipment.

Body Style	Vertical Plug - Standard Orientation
Pitch	3.5mm
No of Ways Per Row	4
No. of Rows	1
Current Rating	8A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/contact	N/A
Connection	Print
Connector model	Other
Connector orientation	Perpendicular (to the PCB)
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Pin
Diameter connection pin	1.2mm
Dim	(L x W x H) 7.25 x 15.40 x 12.60 mm
Height	12.60mm
Housing Colour	Green
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	7.25mm
Length pin	3.4mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	MCV 1,5/ 4-G-3,5
Modular spacing connections	3.5mm
Modular spacing contacts	3.5mm
Nominal Voltage	160V
Number of plug-in contact rows	1
Number of Poles	4
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	MCV
Suitable for PCB thickness	N/Amm
Total number of pins	4
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	15.40mm
