Phoenix Contact 1840434 mini combicon socket housing 9 pins 3.50mm spacing

The socket housing cable by Phoenix Contact features nine pins and a contact spacing of 3.50 mm. It is a screw type connector with a nominal current of 8 A, ideal for use in PCB connections. Common applications include electrical components, connectors, and clamps, ensuring secure and efficient connections.

Body Style	Socket, straight
Pitch	3.5mm
No of Ways Per Row	9
No. of Rows	1
Current Rating	8A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
A	28.00mm
Angle contact/conductor connection	Other
AWG (min.)	28
Case Material	PA
Coating housing	N/A
Connectable cable type	Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 0.5mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.08 - 1.5mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.08 - 1.5mm²
Connector cross section	1.15mm²
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Bus
Degree of protection (IP), mounted	N/A
Dim	(L x W x H) 11.10 x 31.50 x 16.10 mm
Height	16.10mm
Housing Colour	Green
Housing Material	Other
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	11.10mm
Material contact	Copper
Material insulation body	Polyamide (PA)
Material of contact surface	Tin
max. cross section	1.5mm²
Min. cross section	0.14mm²
Misc Attribute	MC 1,5/ 9-ST-3,5
Modular spacing connections	3.5mm
Modular spacing contacts	3.5mm
Nominal Voltage	160V
Number of plug-in contact rows	1
Number of Poles	9
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	MC
Stripping length (max.)	7.00mm
Total number of pins	9
Type of connection	Other
Type of electric connection	Screw connection
Width	31.50mm
With protective conductor	N/A
