Phoenix Contact 1840405 MINI COMBICON-BASIC 6-pin socket housing 3.50mm spacing

Image Representative of Range

Phoenix Contact 1840405 MINI COMBICON-BASIC 6-pin socket housing 3.50mm spacing

Phoenix Contact
Order Code:

06-2089

Brand: Phoenix Contact MPN: 1840405 EAN-13: 2050000437533
Qty Unit Price (Ex VAT)
2+ £3.37
10+ £3.03
25+ £2.74
50+ £2.72
100+ £2.70
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
100 in stock, despatched in 4 working days

Phoenix Contact offers a socket housing cable with six pins and a contact spacing of 3.50 mm. Capable of handling a nominal current of 8 A, this connector is ideal for printed circuit board applications. It is typically used in electrical and electronic systems for reliable connectivity.
Body Style Socket, straight
Pitch 3.5mm
No of Ways Per Row 6
No. of Rows 1
Current Rating 8A
Colour Green
Wire Gauge (AWG) 16AWG
Wire Gauge (mm²) 1.5mm²
A 17.50mm
AWG (min.) 28
Case Material PA
Connector cross section 1.15mm²
Connector System wire-to-board
Contact Material Tin plated
Dim (L x W x H) 11.10 x 21.00 x 16.10 mm
Height 16.10mm
Industrial packaging Yes
Length 11.10mm
max. cross section 1.5mm²
Min. cross section 0.14mm²
Misc Attribute MC 1,5/ 6-ST-3,5
Nominal Voltage 160V
Series MC
Stripping length (max.) 7.00mm
Total number of pins 6
Width 21.00mm
