Phoenix Contact 1830744 pin housing PCB 5 pin 3.5mm spacing SMT-compatible

Phoenix Contact offers this 5-pin housing PCB, featuring a 3.5 mm contact spacing. The product is ideal for securely mounting onto a printed circuit board. It is commonly used in electronic and electrical applications for reliable connectivity.

Body Style	Plug, horizontal mount
Pitch	3.5mm
No of Ways Per Row	5
No. of Rows	1
Current Rating	8A
Colour	Black
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/contact	N/A
Connection	Print
Connector contact surface	Tin
Connector model	Other
Contact Type	Bus
Diameter connection pin	1.1mm
Dim	(L x W x H) 6.3 x 18.3 x 16.35 mm
Height	16.35mm
Housing colour	Black
Inflammability class of insulation material according to UL94	V0
Insulation Material	LCP
Length	6.3mm
Length pin	1.9mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	IMCV 1,5/ 5-G-3,5 P20 THR
Modular spacing connections	3.5mm
Modular spacing contacts	3.5mm
Nominal Voltage	320V
Number of plug-in contact rows	1
Number of Poles	5
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Suitable for PCB thickness	N/Amm
Total number of pins	5
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	18.3mm
