Phoenix Contact 1825433 pin housing cable 14 pins 5.08 mm spacing

Phoenix Contact's pin housing cable with part number 1825433 features 14 pins with a contact spacing of 5.08 mm. It serves as a plug part designed for printed circuit board applications. This component is typically used in electronic and electrical connections requiring secure and reliable connectivity.

Type	Pin housing cable
Number of Circuits	14
Pitch	5.08mm
Wire Gauge	12 AWG
Mounting Type	Cable
Angle contact/conductor connection	Other
AWG (min.)	24
Coating housing	N/A
Connectable cable type	Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 2.5mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2 - 2.5mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.2 - 2.5mm²
Connection	Screws
Connector contact surface	Tin
Connector Type	Plug
Contact Material	Cu-alloy, tin plated
Contact Type	Other
CS	5.08mm
Current Rating	12A
Degree of protection (IP), mounted	N/A
Dim	(L x W x H) 19 x 81.24 x 15 mm
Factory colour	Green
Height	15mm
Housing Colour	Green
Housing Material	Other
Inflammability class of insulation material according to UL94	V0
Insulation Material	PA
Length	19mm
Material contact	Copper
Material insulation body	Polyamide (PA)
Material of contact surface	Tin
max. cross section	2.5mm²
Max. temperature	+100°C
Min. cross section	0.2mm²
Min. temperature	-40°C
Misc Attribute	IC 2,5/14-STF-5,08
Modular spacing connections	5.08mm
Modular spacing contacts	5.08mm
Nominal Voltage	320V
Number of plug-in contact rows	1
Number of Poles	14
Number of Rows	1
Operating Temperature	-40 - 105°C
Overvoltage category	III
Pollution degree	2
Rated current In	12A
Rated Surge Voltage	4kV
Rated voltage	320V
Stripping length (max.)	7mm
Thread Size	M3
Type of connection	Other
Type of electric connection	Screw connection
Width	81.24mm
With protective conductor	N/A
