Phoenix Contact 1814582 Spring-loaded Terminal 4-pin 0.50 mm² White

Phoenix Contact's 1814582 is a spring-loaded terminal with four pins and a 0.50 mm² capacity. This white PCB connector is ideal for secure and reliable electrical connections in printed circuit boards. It is commonly used in various electronic and industrial applications for efficient wiring solutions.

Pitch	2.54mm
No of Ways Per Row	4
No. of Rows	1
Current Rating	6A
Colour	White
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/conductor connection	N/A
AWG (min.)	24
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 0.34mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2 - 0.5mm²
Connectable conductor cross section multi-wired	0.5 - 0.5mm²
Connectable conductor cross section solid-core	0.14 - 0.5mm²
Connection	SMD
Connection type conductor	Spring clamp connection
Connection type PCB	Soldering connection
Connector orientation	Perpendicular (to the PCB)
Contact Material	Tin plated
Cross section (flexible) (min.)	0.20mm²
Cross section (inflexible) (min.)	0.14mm²
Degree of protection (IP), mounted	N/A
Diameter connection pin	N/Amm
Height	10.50mm
Housing Colour	Other
Inflammability class of insulation material according to UL94	V0
Length	5.00mm
Length pin	2.1mm
Material connection surface	Tin
Material insulation body	Other
Min. stripping length	6mm
Misc Attribute	PTSM 0,5/ 4-2,5-V THR WH R44
Modular spacing connections	2.5mm
Nominal Voltage	160V
Number of electrical connections	4
Number of levels	1
Number of Pins	4
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pins	4
Pollution degree	2
Rated current In	6A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	PTSM
Stripping length (max.)	6mm
Type of banding	Blister girdle (for SMD)
Type of fastening	Solder
Type of PCB fastening	Connecting contact
Width	12.10mm
Wire protection	Yes
