Phoenix Contact 1803617 Mini Combicon socket housing 6 pins 3.81 mm spacing

Image Representative of Range

Phoenix Contact 1803617 Mini Combicon socket housing 6 pins 3.81 mm spacing

Phoenix Contact
Order Code:

06-1988

Brand: Phoenix Contact MPN: 1803617 EAN-13: 2050000437625
Qty Unit Price (Ex VAT)
2+ £3.89
125+ £3.50
375+ £3.27
1000+ £2.93
2000+ £2.74
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
100 in stock, despatched in 4 working days

Phoenix Contact offers a socket housing cable with a total of 6 pins and a contact spacing of 3.81 mm. This component, featuring screw type connectors and a nominal current of 8 A, is well-suited for securely connecting cables to conducting boards. Typical applications include electrical and electronic equipment where reliable and compact connections are required.
Body Style Socket, straight
Pitch 3.81mm
No of Ways Per Row 6
No. of Rows 1
Current Rating 8A
Colour Green
Wire Gauge (AWG) 16AWG
Wire Gauge (mm²) 1.5mm²
A 19.05mm
AWG (min.) 28
Case Material PA
Connector cross section 1.15mm²
Connector System wire-to-board
Contact Material Tin plated
Dim (L x W x H) 11.10 x 23.65 x 16.10 mm
Height 16.10mm
Industrial packaging Yes
Length 11.10mm
max. cross section 1.5mm²
Min. cross section 0.14mm²
Misc Attribute MC 1,5/ 6-ST-3,81
Nominal Voltage 160V
Series MC
Stripping length (max.) 7.00mm
Total number of pins 6
Width 23.65mm
