Phoenix Contact 1803316 Mini Combicon housing 6 pins 3.81mm spacing

Image Representative of Range

Phoenix Contact 1803316 Mini Combicon housing 6 pins 3.81mm spacing

Phoenix Contact
Order Code:

06-1959

Brand: Phoenix Contact MPN: 1803316 EAN-13: 2050000437809
Qty Unit Price (Ex VAT)
2+ £2.15
75+ £2.02
250+ £1.72
500+ £1.59
1000+ £1.52
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 9 days

Phoenix Contact manufactures a pin housing for PCBs with a total of six pins and a contact spacing of 3.81 mm. This component supports a nominal current of 8 A and is ideal for use in electronic connectors and clamps. It is typically used in various electrical and electronic applications where reliable and secure connections are needed.
A 19.05mm
Connection Print
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Plug, horizontal mount
Contact Material Tin plated
CS 3.81mm
Dim (L x W x H) 9.20 x 24.25 x 10.65 mm
Factory colour Green
Height 10.65mm
Industrial packaging Yes
Length 9.20mm
Misc Attribute MC 1,5/ 6-G-3,81
Nominal Current 8A
Nominal current - rounded value 8A
Nominal current (details) 8A
Nominal Voltage 160V
Number of Rows 1
Pins per row 6
Series MC
Total number of pins 6
Type Pin housing PCB
Width 24.25mm
