Phoenix Contact 1803277 Mini Combicon Pin housing 2 pins 3.81mm compact

The Phoenix Contact pin housing PCB MC has 2 pins with a contact spacing of 3.81 mm. It supports a nominal current of 8 A and is commonly used for connecting components in electronic assemblies. Typical applications include use in printed circuit boards for secure electrical connectivity.

Body Style	Plug, horizontal mount
Pitch	3.81mm
No of Ways Per Row	2
No. of Rows	1
Current Rating	8A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
A	3.81mm
Angle PCB/contact	N/A
Connection	Print
Connector model	Other
Connector orientation	Parallel (to the PCB)
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Pin
Diameter connection pin	1.2mm
Dim	(L x W x H) 9.01 x 10.65 x 9.20 mm
Height	9.20mm
Housing Colour	Green
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	9.01mm
Length pin	3.4mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	MC 1,5/ 2-G-3,81
Modular spacing connections	3.81mm
Modular spacing contacts	3.81mm
Nominal Voltage	160V
Number of plug-in contact rows	1
Number of Poles	2
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	MC
Suitable for PCB thickness	N/Amm
Total number of pins	2
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	10.65mm
