Phoenix Contact 1776896 MSTBV 2,5/ 3-GF PCB header - PCB headers, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Sn, contact connection type: Pin, number of potentials: 3, number of rows: 1, number of positions: 3, number of connections: 3, product range: MSTBV 2,5/..-GF, pitch: 5 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.9 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2,5, Pin connector pattern alignment: Standard, locking: Screw locking mechanism, mounting: Threaded flange, type of packaging: packed in cardboard.
- Pitch: 5 mm
- Width [w]: 25 mm
- Height [h]:15.9 mm
- Length [l]: 8.6 mm
- Installed height: 12 mm
- Solder pin length [P]: 3.9 mm
- Pin dimensions: 1 x 1 mm
| Pitch |
5mm |
| No of Ways Per Row |
3 |
| No. of Rows |
1 |
| Current Rating |
12A |
| Colour |
Green |
| Wire Gauge (AWG) |
N/A |
| Wire Gauge (mm²) |
N/A |
| Angle PCB/contact |
N/A |
| Connector model |
Other |
| Contact Finish |
Tin-plated |
| Contact Type |
Pin |
| Diameter connection pin |
1.4mm |
| Housing Colour |
Green |
| Inflammability class of insulation material according to UL94 |
V0 |
| Length pin |
3.9mm |
| Material insulation body |
Other |
| Material of contact surface |
Other |
| Modular spacing connections |
5mm |
| Modular spacing contacts |
5mm |
| Mounting Type |
PCB |
| Number of plug-in contact rows |
1 |
| Number of Poles |
3 |
| Operating Temperature |
-40 - 105°C |
| Overvoltage category |
III |
| Pollution degree |
2 |
| Rated current In |
12A |
| Rated Surge Voltage |
4kV |
| Rated voltage |
320V |
| Suitable for PCB thickness |
N/Amm |
| Type of banding |
Carton (for SMD) |
| Type of connection |
N/A |
| Type of electric connection |
Other |
| Type of fastening |
Other |
| Type of PCB fastening |
N/A |
