Phoenix Contact 1759062 MSTB Pin Housing 7 Pins 5.08mm plug parallel PCB

Phoenix Contact pin housing PCB MSTB is manufactured by Phoenix Contact and features a total of seven pins with a contact spacing of 5.08 mm. This connector is typically used in electronic and electrical applications where secure connections to a printed circuit board (PCB) are required. It is ideal for assembling components in various electrical and electronic systems.

Body Style	Horizontal Open End Header
Pitch	5.08mm
No of Ways Per Row	7
No. of Rows	1
Current Rating	12A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Actuation direction	Parallel (to the PCB)
Angle PCB/contact	N/A
Board contact surface	Tin plated
Case Material	Polyamide
Connection	Print
Connector contact surface	Tin plated
Connector model	Other
Connector orientation	Parallel (to the PCB)
Connector System	wire-to-board
Contact Material	Cathode copper
Contact Type	Pin
Contamination level	3
Diameter connection pin	1.4mm
Dim	(L x W x H) 12.00 x 35.56 x 12.10 mm
Height	12.10mm
Housing colour	Green
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	12.00mm
Length pin	3.23mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	MSTB 2,5/ 7-G-5,08
Modular spacing connections	5.08mm
Modular spacing contacts	5.08mm
Nominal Voltage	320V
Number of plug-in contact rows	1
Number of Poles	7
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pin Ø	1mm
Pin shape	Rectangular
Pollution degree	2
Rated current In	12A
Rated Surge Voltage	4kV
Rated voltage	320V
Series	MSTB
Suitable for PCB thickness	N/Amm
Total number of pins	7
Type	Pin housing PCB
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	35.56mm
