Phoenix Contact 1754830 PCB Connector FKCN 2,5/ 6-STF-5,08 - PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Sn, contact connection type: Socket, number of potentials: 6, number of rows: 1, number of positions: 6, number of connections: 6, product range:
FKCN 2,5/..-STF, pitch: 5.08 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 0 °, locking clip: - Locking clip, plug-in system:
COMBICON MSTB 2,5, locking: Screw locking mechanism, mounting: Screw flange, type of packaging: packed in cardboard.
- Nominal current:12 A
- Nominal voltage:320 V
- Contact resistance:1.1 mΩ
- Rated voltage: 320 V
| Pitch |
5.08mm |
| No. of Ways |
6 |
| Mounting Type |
PCB |
| Wire Gauge (AWG) |
24 to 16AWG |
| Wire Termination |
Screwless |
| Angle contact/conductor connection |
Other |
| Body Style |
Plug |
| Coating housing |
N/A |
| Colour |
Green |
| Connectable cable type |
Tubular cable |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.25 - 1.5mm² |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.2 - 2.5mm² |
| Connectable conductor cross section multi-wired |
- - -mm² |
| Connectable conductor cross section solid-core |
0.2 - 1.5mm² |
| Contact Resistance |
1.1 mO |
| Contact Type |
Bus |
| Current Rating |
12A |
| Degree of protection (IP), mounted |
N/A |
| Housing Colour |
Green |
| Housing Material |
Other |
| Inflammability class of insulation material according to UL94 |
V0 |
| Material contact |
Copper |
| Material insulation body |
Polyamide (PA) |
| Material of contact surface |
Tin |
| Mating Feature |
Socket |
| Modular spacing connections |
5.08mm |
| Modular spacing contacts |
5.08mm |
| Mounting - Header |
Screw Locking Mechanism |
| Mounting Feature |
Screw Flange |
| No. of Rows |
1 |
| Number of plug-in contact rows |
1 |
| Number of Poles |
6 |
| Number of Ways Per Row |
6 |
| Operating Temperature |
-40 - 100°C |
| Overvoltage category |
III |
| Pollution degree |
2 |
| Rated current In |
12A |
| Rated Surge Voltage |
4kV |
| Rated voltage |
320V |
| Type of connection |
Other |
| Type of electric connection |
Spring clamp connection |
| Voltage Rating |
320V |
| With protective conductor |
N/A |
