Phoenix Contact 1753437 12A Pluggable 2-way Terminal Block 5mm

MPN: 1753437
Brand: Phoenix Contact
EAN-13: 2050000258794
Order Code: 51-4831

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
10+	£0.443

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 1

Despatched within 4 working days - 222 in stock

Product Details

Pluggable 12A PCB terminal block from Phoenix Contact, 5mm pitch with 2 poles.

Green colour
Tin contacts
Mini Combicon plug
Low construction height
Without side walls
Vertical mounting
Phoenix type MSTBV 2.5/2-G

Pitch	5mm
No. of Rows	1
Current Rating	12A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/contact	N/A
Connector model	Other
Contact Type	Pin
Diameter connection pin	1.4mm
Housing Colour	Green
Inflammability class of insulation material according to UL94	V0
Length pin	3.9mm
Material insulation body	Other
Material of contact surface	Other
Modular spacing connections	5mm
Modular spacing contacts	5mm
Number of plug-in contact rows	1
Number of Poles	2
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	12A
Rated Surge Voltage	4kV
Rated voltage	320V
Suitable for PCB thickness	N/Amm
Type	Pin housing PCB
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
