Phoenix Contact 1078963 PG Terminal 5.2mm push-in green/yellow 50 pcs

Phoenix Contact's 1078963 model is a 5.2 mm push-in green and yellow connector typically utilised in switchboards. It features durability and continuity, designed for easy terminal connections. This PG terminal is widely used in electrical installations for effective serial terminal connections.

Type	PG terminal
Pitch	5.2mm
No. of Ways	2
Termination	Push-in Cage clamp
Width	5.2mm
Wire Gauge (mm²)	4mm²
AWG (min.)	26
Clamp width	5.2mm
Closing plate required	true
Colour	Green/yellow
Connectable conductor cross section fine-strand with cable end sleeve	0.14 - 2.5mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.14 - 4mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.14 - 4mm²
Connection	Push-in connector
Cross section (flexible) (min.)	0.14mm²
Cross section (inflexible) (min.)	0.14mm²
Depth	35.3mm
Height	50.8mm
Inflammability class of insulation material according to UL94	V0
Material insulation body	Thermoplastic
Maximum Wire Size AWG	12
Min. stripping length	8mm
Misc Attribute	PTV 2,5-PE
Mounting method	DIN rail (top hat rail) 35 mm
Number of clamp positions per level	2
Number of levels	1.0
Operating Temperature	-60 - 110°C
PEN function possible	false
Stripping length (max.)	10mm
Type of electrical connection 1	Other
Type of electrical connection 2	Other
Wire Gauge (AWG)	12
