Phoenix Contact manufactures the 1078960 Continuity connector, a 5.2 mm push-in connector that comes in packs of 50. This grey-coloured connector is designed for switchboard and serial terminal applications, ensuring reliable continuity in electrical systems. It is commonly used in industrial and commercial settings for efficient wiring and secure connections.
| Type |
Continuity |
| Pitch |
5.2mm |
| No. of Ways |
2 |
| Termination |
Push-in Cage clamp |
| Width |
5.2mm |
| Wire Gauge (mm²) |
4mm² |
| AWG (min.) |
26 |
| Clamp width |
5.2mm |
| Closing plate required |
true |
| Colour |
Grey |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.14 - 0.14mm² |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.14 - 4mm² |
| Connectable conductor cross section multi-wired |
- - -mm² |
| Connectable conductor cross section solid-core |
0.14 - 4mm² |
| Connection |
Push-in connector |
| Cross section (flexible) (min.) |
0.14mm² |
| Cross section (inflexible) (min.) |
0.14mm² |
| Current Rating |
24A |
| Depth |
35.3mm |
| Explosion-tested version Ex e |
true |
| Height |
50.8mm |
| Inflammability class of insulation material according to UL94 |
V0 |
| Internally connected stages |
true |
| Material insulation body |
Other |
| Maximum Wire Size AWG |
12 |
| Min. stripping length |
8mm |
| Misc Attribute |
PTV 2,5 |
| Mounting method |
DIN rail (top hat rail) 35 mm |
| Nominal Voltage |
800V |
| Number of clamp positions per level |
2 |
| Number of levels |
1.0 |
| Number of pins |
1 |
| Number of Rows |
1 |
| Operating Temperature |
-60 - 110°C |
| Rated current In |
24A |
| Rated voltage |
800V |
| Stripping length (max.) |
10mm |
| Suitable for conductor material |
Aluminium/copper |
| Type of electrical connection 1 |
Other |
| Type of electrical connection 2 |
Other |
| Wire Gauge (AWG) |
12 |
