Phoenix Contact 0404033 AK 16 Pick-off Terminal Block 76A Screw 1.5-16mm²

Phoenix Contact manufactures the Pick-off terminal block AK 16 0404033, which functions as a D-sub adapter and gender changer. This built-in coupling adapter facilitates the conversion of signals in switchboard and serial terminal interfaces, ensuring continuity in data transmission. Typically, it is used in electronic applications requiring reliable connectivity and adaptability within infrastructure systems.

Colour	Silver
Current Rating	76A
Type	Terminal
Number of Ways	2
Busbar thickness	3 - 6mm
Busbar width	6 - 10mm
Clamp width	9.8mm
Connection	Screws
Connection (type)	Screw Terminal
Connections	2
Contact Material	Copper
Content	50
Current Rating (A)	76
Dim	(L x W) 16 mm x 9.8 mm
Flammability Rating	V2
Industrial packaging	Yes
Insulation	PA
Insulation Material	PA
Length	16mm
Length (mm)	16mm
Material (details)	Polyamide
Max. conductor cross section	16mm²
Max. rated operation current Ie	N/AA
Misc Attribute	AK 16
Nominal Current	76 A
Product Type	Tap Terminal
Stripping length (max.)	16mm
Stripping length (max.) mm	16mm
Suitable For	Flat rail
Suitable for round conductor connection	false
Suitable for sector conductor connection	false
Suitable for strip conductor connection	false
Voltage Rating (V, V DC)	250 V
Weight (g, g/m)	9.5
Width	9.8mm
Width (mm)	9.8
Width clamp	9.8mm
Wire Gauge	6
