Panasonic PM-L25-R Light Barrier Small Fork Design 5-24V DC Dual Output

Name: Panasonic PM-L25-R Light Barrier Small Fork Design 5-24V DC Dual Output
Brand: Panasonic
Price: 41.19 GBP
Availability: InStock

Standard range

Order Code:

05-7024

Brand: Panasonic MPN: PM-L25-R

RoHS Compliant
Country of Origin: Japan
Free UK shipping available
View Full Product Range (4)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£41.19

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

13 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Panasonic PM-L25-R is a reflective light barrier designed for Light-ON/Dark-ON operation within a 5 - 24 V DC range. It is typically used in applications requiring precise object detection and positioning. Ideal for automated systems, this sensor ensures reliable performance in various industrial environments.

Type	Reflective light barrier
Cable length	1.00m
Connector	Cable, open end
Dim	(L x W x H) 13.4 x 12 x 12 mm
Enclosure material	PBT
Height	12mm
IP rating	IP64
Length	13.4mm
Max. operating voltage	24V DC
Max. temperature	+55°C
Min. operating voltage	5V DC
Min. temperature	-25°C
Misc Attribute	PM-L25-R
Model	L
Operating voltage	5 - 24 V DC
Outputs	NPN
Transmitter type	LED IR
Wavelength	855nm
Width	12mm
