Panasonic PM-F25 Fork Light Beam Small Transistor Outputs LED Display

Panasonic PM-F25 Fork Light Beam Small Transistor Outputs LED Display

Panasonic
Order Code:

05-7007

Brand: Panasonic MPN: PM-F25 EAN-13: 2050004799286

Discontinued


Panasonic's PM-F25 is a reflective light barrier operating between 5 to 24 V DC. Key features include Light-ON and Dark-ON functionality, making it versatile for various detection applications. It is commonly used in automation systems for object detection and positioning.
Type Reflective light barrier
Output Type NPN
IP Rating IP64
Cable Length 1.00m
Connector Cable, open end
Dim (L x W x H) 13.4 x 11.7 x 12.5 mm
Enclosure material PBT
Height 12.5mm
Length 13.4mm
Max. operating voltage 24V DC
Max. temperature +55°C
Min. operating voltage 5V DC
Min. temperature -25°C
Model F
Operating Voltage 5 - 24 V DC
Transmitter type LED IR
Wavelength 855nm
Width 11.7mm
