Panasonic EX13B One-way Light Barrier 0.5ms Detects 2mm Objects

Panasonic
Standard range
Order Code:

05-6918

Brand: Panasonic MPN: EX13B
Qty Unit Price (Ex VAT)
1+ £92.28
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

Panasonic manufactures the EX13B one-way light barrier, designed for precise object detection. This compact sensor operates in Dark-ON mode and is ideal for automation and safety applications. Common uses include detecting presence or absence of objects in conveyors and sorting systems.
Type One-way light barrier
Cable length 2.00m
Connector Cable, open end
Depth 14.5mm
Dim (W x H x D) 3.5 x 10 x 14.5 mm
Functions Dark-ON
Height 10mm
IP rating IP67
Max. operating voltage 24V DC
Max. range 0.5m
Max. temperature +55°C
Min. operating voltage 12V DC
Min. temperature -25°C
Misc Attribute EX13B
Model Front
Operating voltage 12 - 24 V DC
Outputs NPN
Response time 0.5ms
Width 3.5mm
