Panasonic EX13A Light Barrier for Small Objects Fast Flat Design

Panasonic manufactures the EX13A light barrier, which is a one-way light barrier designed for reliable sensing. This device features a front light-on sensor, ideal for applications requiring precise object detection. Typical uses include automation systems, safety interlocks, and production line monitoring.

Type	One-way light barrier
Cable Length	2.00m
Connector	Cable, open end
Depth	14.5mm
Dim	(W x H x D) 3.5 x 10 x 14.5 mm
Functions	Light-ON
Height	10mm
IP Rating	IP67
Max. operating voltage	24V DC
Max. Range	0.5m
Max. temperature	+55°C
Min. operating voltage	12V DC
Min. temperature	-25°C
Model	Front
Operating Voltage	12 - 24 V DC
Output Type	NPN
Response Time	0.5ms
Width	3.5mm
