Panasonic ADW1112HLW DW-HL Relay 12V DC 16A Compact KNX/IoT Ready

The Panasonic ADW1112HLW is a PCB relay designed for 12 V DC applications, handling a current of up to 16 A. Its compact size makes it suitable for printed circuit boards, ensuring efficient space utilisation. Typically, this relay is used in automotive, industrial, and consumer electronics for reliable switching operations.

Coil Voltage	12V DC
Contact Configuration	1NO
Switching Current	16A
Coil Resistance	720O
Connection	Print
Contact Material	AgSnO2
Control Mode	Bistable, 1 Coil
Dimensions	(L x W x H) 24 x 10 x 15.8 mm
Height	15.8mm
Length	24.0mm
Max. switching capacity	4432VA
Max. temperature	+85°C
Minimum Temperature	-40°C
Mounting Type	PCB
Switching Voltage Max	277V AC
Type	PCB relay
Width	10.0mm
