Omron SSG-5P-5 Subminiature Basic Switch Compact Snap Action Silicon

Inc VAT

Qty	Unit Price (Ex VAT)
15+	£1.76

Sign in for personalised pricing

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 15

Available to back orderBack order, lead time 4 months

The Omron SSG-5P-5 is a compact snap-action switch with a long operating life.

This subminiature switch features a silicon plunger and a small footprint ideal for space-constrained applications.

It is typically used in home appliances and office equipment.

The design allows precise and reliable operation suited for demanding environments.

Type	Limit Switch
Contact Configuration	SPDT
Switch Function	On/(On)
Voltage Rating - AC	250 VAC
Voltage Rating - DC	N/A (AC Rated)
Actuator Type	Pin Plunger
Contact AC Voltage	250V ac
Contact DC Voltage	30V dc
Hazardous Area Certification	No
IP Rating	IP40
Maximum Operating Temperature	125°C
Mechanical Life	10000000Operations
Microswitch Type	Subminiature
Minimum Operating Temperature	25°C
Operating Force	0.5N
Product Type	Subminiature Micro Switch
Series	SSG
Standards/Approvals	RoHS
Switch Contact Current	5A
Terminal Type	PCB Terminal
