Neomounts DS70S-950WH2 Monitor desk mount is a versatile and robust solution designed for securely positioning monitors ranging from 43.2 cm (17 inches) to 88.9 cm (35 inches) in size. It features a sleek black finish and offers a range of adjustability options, including height adjustment, tilt, and swivel capabilities, allowing for ergonomic positioning and optimised viewing angles. The mount is engineered for compatibility with a wide range of displays and is well-suited for use in office environments, control rooms, and technical workstations where adjustability and durable construction are paramount. Its engineering-focused design allows for efficient space utilisation while maintaining a strong, stable hold on the monitor, ensuring reliability in professional settings.
| Type |
Monitor desk mount |
| Add-on displays |
2 |
| Adjustable depth |
Yes |
| Angle of rotation |
360° |
| Cable management |
Yes |
| Clamp mount desk thickness (max) |
5 cm |
| Colour |
Black |
| Country of origin |
China |
| Depth |
656mm |
| Depth adjustment range |
88 - 625 mm |
| Desk thickness (max) |
5.5 cm |
| Desk thickness (min) |
1 cm |
| Dimensions |
(W x H x D) 186 x 579 x 656 mm |
| Distance to the wall (max) |
65.6 cm |
| Distance to the wall (min) |
11.9 cm |
| Distance to wall (max.) |
656mm |
| Distance to wall (min.) |
119mm |
| Easy to install |
Yes |
| Grommet mount desk thickness (max) |
5.5 cm |
| Harmonized System (HS) code |
7616991099 |
| Height |
579mm |
| Height adjustment |
Yes |
| Height adjustment range |
202 - 522 mm |
| Height adjustment type |
Gas spring |
| Housing Material |
Aluminium |
| Master (outer) case gross weight |
16.3 kg |
| Master (outer) case height |
505mm |
| Master (outer) case length |
320mm |
| Master (outer) case net weight |
14 kg |
| Master (outer) case width |
260mm |
| Material (details) |
Aluminium |
| Max. load Capacity |
36kg |
| Maximum screen size |
88.9 cm (35) |
| Maximum VESA mount |
100 x 100 mm |
| Maximum weight capacity |
18 kg |
| Maximum weight capacity (per curved/ultra-wide display) |
15 kg |
| Maximum weight capacity (per display) |
18 kg |
| Minimum screen size |
43.2 cm (17) |
| Minimum VESA mount |
75 x 75 mm |
| Minimum weight |
1 kg |
| Mounting |
Clamp/Grommet |
| Mounting Type |
Desk |
| Number of arms |
2 |
| Number of displays supported |
2 |
| Package depth |
124mm |
| Package height |
496mm |
| Package net weight |
7.9 kg |
| Package type |
Box |
| Package weight |
7.9 kg |
| Package width |
410mm |
| Panel mounting interface |
100 x 100,75 x 75 mm |
| Pivot angle |
-180 - 180° |
| Pneumatic technology |
Yes |
| Product colour |
White |
| Products per master (outer) case |
2 pc(s) |
| Products per pallet (EU) |
48 pc(s) |
| Rotating |
Yes |
| Rotation |
360° |
| Suitable For |
43,2 cm (17") - 88,9 cm (35") |
| Swivel angle range |
-90 - 90° |
| Swivel Range (left) |
90° |
| Swivel Range (right) |
90° |
| Swivelling |
Yes |
| Tilt adjustment |
Yes |
| Tilt angle range |
-90 - 90° |
| Tilt Range (bottom) |
90° |
| Tilt Range (top) |
90° |
| Warranty period |
10 year(s) |
| Weight |
7.117 |
| Width |
186mm |
| Width adjustment |
115.9cm |
| Width adjustment range |
0 - 1159 mm |
