MW XDR-120E-36 Power Supply Units Open & DIN 36V 3.33A 120W Compact

Mean Well XDR-120E-36 is a 36V, 3.33A industrial power supply unit providing 120W of power. This compact device is part of Mean Well's range of open and DIN rail power supply units, specifically engineered for seamless integration into rail mount systems. Designed for robustness, it offers dependable performance in demanding industrial settings. The unit is versatile for use in automated machinery, electrical control panels, and various industrial control applications. Its configuration ensures easy installation and maintenance, making it a reliable choice for engineers seeking a durably constructed power supply solution.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	120W
Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 116 x 30 x 125.2 mm
Efficiency	91%
Height	125.2mm
Input voltage (max.)	264V
Length	116mm
Max. output current	3.33A
Maximum Temperature	-40°C
Min. input voltage	85V
Minimum Temperature	+70°C
Operating temperature (max.)	+70°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	3.33A
Output voltage (max.)	36V
Output voltage (nominal)	36V
Power	119.88W
Product Type	Rail mounted PSU (DIN)
Width	30mm
