Mean Well's XDR-75E-12 is a reliable and efficient open-style DIN rail power supply unit designed to deliver a stable 12V DC output at a maximum power of 75W. Engineered for use in a wide range of industrial applications, this rail mount power supply unit is ideal for control systems and automation equipment that demand consistent performance and robustness. The XDR-75E-12 boasts high efficiency and features an easy installation process onto DIN rails, making it suitable for cabinet-mounted configurations where space and reliability are critical. Its wide input voltage range and integrated overload protection enhance its versatility and ensure compliance with various industrial standards. Whether employed in power distribution panels or used as a component in complex machinery setups, this unit satisfies the stringent requirements of modern industrial environments.
| Type |
Rail mounted PSU (DIN) |
| Number of Outputs |
1 |
| Power Rating |
75W |
| 1st secondary output voltage |
12V |
| 2nd secondary output voltage |
12V |
| 3rd secondary output voltage |
12V |
| Content |
1 |
| Depth |
116mm |
| Dimensions (L x W x H) |
116 x 30 x 125.2mm |
| Efficiency |
89% |
| Height |
125.2mm |
| IP Rating |
Protection class I |
| Max. output current 1 |
6.3A |
| Max. temperature |
-40°C |
| Maximum input voltage |
264V |
| Maximum Operating Temperature |
+70°C |
| Maximum Temperature |
-40°C |
| Min. temperature |
+70°C |
| Minimum Input Voltage |
85V |
| Minimum Operating Temperature |
+70°C |
| Nominal value output voltage 1 |
12V |
| Operating temperature (min.) |
-40°C |
| Output current (max.) - rounded |
6.3A |
| Output voltage (max.) |
12V |
| Output voltage stabilized |
12V |
| Power |
75.6W |
| Product Type |
Rail mounted PSU (DIN) |
| Rated supply voltage AC 50 Hz |
12V |
| Rated supply voltage AC 60 Hz |
12V |
| Rated supply voltage DC |
12V |
| Type of electric connection |
Screw terminal |
| Width |
30mm |
