MW Mean Well XDR-150E-48 Power Supply Unit 48V 150W DIN Rail Mountable

Mean Well's XDR-150E-48 is a robust DIN rail mountable power supply unit engineered for industrial applications requiring reliable 48V DC output at 150W. Designed as an open and DIN power supply unit, it offers easy integration into industrial control panels and systems that necessitate compact and efficient power conversion solutions. Its versatile design ensures efficient operation under demanding conditions, making it suitable for use in automation, machinery, and other industrial environments where stable electrical power is critical. Known for its durability and performance, the XDR-150E-48 is an ideal choice for engineers seeking a dependable power supply module within a DIN mount configuration.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	150W
Content	1
Depth	116mm
Dimensions (L x W x H)	116 x 30 x 125.2mm
Efficiency	91%
Height	125.2mm
IP Rating	Protection class I
Max. output current 1	3.25A
Max. temperature	-40°C
Maximum input voltage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Voltage	85V
Minimum Operating Temperature	+70°C
Nominal value output voltage 1	48V
Operating temperature (min.)	-40°C
Output current (max.) - rounded	3.25A
Output voltage (max.)	48V
Power	156W
Product Type	Rail mounted PSU (DIN)
Type of electric connection	Screw terminal
Width	30mm
