Murrelektronik 6686311 Control Transformer 1x230V 1000VA Keyhole Mount

Murr Elektronik
Order Code:

05-4956

Brand: Murr Elektronik MPN: 6686311 EAN-13: 4048879066198
Qty Unit Price (Ex VAT)
1+ £144.51
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 available to back orderBack-order availability date - 21/12/2025

The Murrelektronik 6686311 is a control transformer designed for automation applications, with an input voltage of 400 V and an output of 230 V AC, delivering 1000 VA power. This isolation transformer is ideal for ensuring safe and reliable power supply to sensitive electrical systems. Its compact dimensions of 174x128x160 mm make it suitable for integration into various industrial environments.
Type Control transformer
Connection Spring-loaded terminal
Dim (L x W x H) 160 x 174 x 128 mm
Frequency 50 - 60Hz
Height 128mm
Input Voltage 230/400V AC
Input voltage (number x voltage) 1 x 230 V, 400 V
Insulation class T 40/B
Length 160mm
Max. ambient temperature +40°C
Min. ambient temperature -20°C
Misc Attribute MST 1000-230-400/230
Number of Inputs 1
Number of Outputs 1
Output Voltage 230V AC
Output voltage (number x voltage) 1 x 230 V AC
Power 1000VA
Primary Voltage 230/400V AC
Protection Class IP20
Standards Complies with EN 61558 · Contact protection as per EN 60529
Width 174mm
