Mean Well XLG-150-L-A XLG-series LED driver 150W 350-1050mA adjustable

Mean Well
Order Code:

05-1924

Brand: Mean Well MPN: XLG-150-L-A EAN-13: 4021087051637
Qty Unit Price (Ex VAT)
1+ £29.62
10+ £26.66
25+ £25.93
50+ £25.73
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well XLG-150-L-A LED driver is a constant power unit that outputs 150 W, with a current range of 350 to 1050 mA and a voltage range of 120 to 214 V DC. Featuring a power factor correction circuit, it is approved for use on furniture and outdoor applications, and it includes adjustable, surge protection, and overvoltage features. This LED driver is suitable for installation on flammable surfaces, making it ideal for powering LED strips,
Type LED driver
Connection Open end cable
Dim (L x W x H) 180 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 180mm
Max. output current 1050mA
Max. power 150W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant power
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.05A
Output current (min.) 350mA
Output voltage (max.) 214V DC
Output voltage (min.) 120V DC
Power range 150 W (max)
Test mark CE, CB, MM, ENEC, UL
Width 63mm
