Mean Well XLG-150-12-A LED driver 150W 12V DC outdoor use

Mean Well
Order Code:

05-1920

Brand: Mean Well MPN: XLG-150-12-A EAN-13: 4021087051675
Qty Unit Price (Ex VAT)
1+ £36.44
10+ £32.80
25+ £31.49
50+ £30.43
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well XLG-150-12-A is a 150 W LED driver featuring constant voltage and constant current operation, with an output of 12 V DC and current range of 6.25 - 12.5 A. It includes surge protection, a PFC circuit, and is suitable for outdoor use and flammable surfaces, as well as being approved for use on furniture. This adjustable power supply unit is ideal for LED lighting applications in both indoor and outdoor environments.
Type LED driver
Connection Open end cable
Dim (L x W x H) 180 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 180mm
Max. output current 12.5A
Max. power 150W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 12.5A
Output current (min.) 6.25A
Output voltage (max.) 12V DC
Power range 150 W (max)
Test mark CE, CB, MM, ENEC, UL
Width 63mm
