Mean Well TDR-960-48 TDR PSU 48V 20A 960W DIN Rail mounted input 340-550V AC

The Mean Well TDR-960-48 is a rail-mounted power supply unit designed for industrial applications, offering a 48 V DC output with a current rating of 20 A and a total power of 960 W. It features an enclosed design suitable for DIN rail mounting, ensuring easy integration and reliable performance in control panels. This power supply is ideal for use in machinery, automation systems, and other industrial environments requiring robust and efficient power.

Type	Rail mounted PSU (DIN)
Nominal value output current 1	20A
Number of Outputs	1
Power Rating	960W
Depth	110.00mm
Dimensions (L x W x H)	110.00 x 125.20 x 150.00mm
Height	150.00mm
Max. output current 1	20A
Maximum input voltage [AC]	550V
Minimum Input Voltage [AC]	340V
Misc Attribute 1	Synchronised
Nominal value output voltage 1 [DC]	48V
Number of Inputs	1
Type of electric connection	Screw terminal
Weight	2466.67g
Width	125.20mm
