Mean Well SKMW30F-05 converter 30W 6A 1 output -40 to +85°C range

Mean Well
Extended range
Order Code:

05-1773

Brand: Mean Well MPN: SKMW30F-05
Qty Unit Price (Ex VAT)
1+ £37.11
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 7 weeks

The Mean Well SKMW30F-05 is a DC/DC converter that delivers 6 A and 30 W with a single output. It is typically used in applications requiring efficient energy conversion and stable power delivery. Ideal for electronic devices, this converter offers reliability in converting direct current.
Type DC/DC converter
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 90%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 25.4mm
Max. output current 6A
Min. input voltage 9V DC
Misc Attribute SKMW30F-05
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 6A
Output voltage (max.) 5V DC
Power 30W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 18g
Width 25.4mm
