Mean Well SFTN01M-12 DC/DC converter 1W 84mA single output -40°C to 90°C

Mean Well
Order Code:

05-1714

Brand: Mean Well MPN: SFTN01M-12 EAN-13: 4021087041669
Qty Unit Price (Ex VAT)
1+ £4.70
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
5 in stock, despatched in 4 working days

The Mean Well SFTN01M-12 is a DC/DC converter module with 1 output providing 1 W of power at 84 mA. It features a compact design suitable for efficient power conversion and integration into various electronic applications. This converter is typically used for powering sensitive electronic circuits where isolated voltage regulation is required.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 82%
Height 7.1mm
Input voltage (max.) 13.2V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 10.8V DC
Number of Outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 8.4mA
Output voltage (max.) 12V DC
Power 1W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
