Mean Well SCWN06C-05 SCWN06 DC/DC converter 1A 6W single output DIP24

Mean Well
Standard range
Order Code:

05-1667

Brand: Mean Well MPN: SCWN06C-05
Qty Unit Price (Ex VAT)
1+ £8.89
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well SCWN06C-05 is a DC/DC converter module rated at 1 A and 6 W, designed to convert direct current efficiently. It features a single output, making it suitable for applications requiring a stable power supply, such as telecommunications and industrial control systems. With its compact design and reliable performance, this converter is ideal for integration into various electronic systems.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 83%
Height 10.2mm
Input voltage (max.) 72V DC
Insulation voltage 3000V DC
Length 31.8mm
Max. output current 1A
Min. input voltage 36V DC
Misc Attribute SCWN06C-05
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1A
Output voltage (max.) 5V DC
Power 6W
PSU features DC-to-DC converter
Weight 12.5g
Width 20.3mm
