Mean Well SCWN06B-15 SCWN06 DC/DC converter 6W 1 output 400mA DIP24.

Mean Well
Order Code:

05-1665

Brand: Mean Well MPN: SCWN06B-15 EAN-13: 4021087048040
Qty Unit Price (Ex VAT)
1+ £9.45
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SCWN06B-15 is a direct current converter module with a single output, delivering 6 watts and a current of 400 mA. This compact DC/DC converter is ideal for applications requiring efficient voltage regulation and conversion in electronic devices. Its robust design makes it suitable for use in various industrial and commercial power supply systems.
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 86%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 400mA
Min. input voltage 18V DC
Number of Outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 400mA
Output voltage (max.) 15V DC
Power 6W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
