Mean Well RSP-1500-5 SMPSU 5.5V DC 240A 1200W reliable power supply

The Mean Well RSP-1500-5 is a switched-mode power supply unit delivering 5.5 V DC at 240 A, with a total power of 1200 W. It features screw terminals for secure connections and is suitable for printed circuit board mounting. This power supply is ideal for high-current applications where reliable, efficient power conversion is required.

Output Voltage [DC]	5.5V
Output Current	240A
Power Rating	1200W
Number of Outputs	1
Input Voltage	264V AC
Connection	Screw terminal
Dimensions	(L x W x H) 278 x 127 x 83.5 mm
Height	83.5mm
Length	278mm
Maximum Operating Temperature	+70°C
Maximum Temperature	+70°C
Min. temperature	-20°C
Minimum Input Volage	90V AC
Misc Attribute 2	closed
MTBF	265.300h
Operating temperature (min.)	-20°C
Output Voltage	4.5V DC
PFC	Yes
PSU features	Adjustable voltage output
Type	SMPSU
Weight	3.000g
Width	127mm
