Mean Well RSDW10H-15 DC/DC converter 10W 666mA Output: 1 Content: 1pc

Name: Mean Well RSDW10H-15 DC/DC converter 10W 666mA Output: 1 Content: 1pc
Brand: Mean Well
Price: 18.14 GBP
Availability: InStock

Standard range

Order Code:

05-1555

Brand: Mean Well MPN: RSDW10H-15

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (15)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£18.14

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

3 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well RSDW10H-15 is a DC/DC converter with a 666 mA current rating and a 10 W power output. It features a single output and is designed for efficient direct current conversion. Typical applications include industrial automation, telecommunications, and transport systems.

Type	DC/DC converter
Connection	Pins
Dim	(L x W x H) 31.8 x 20.3 x 12.7 mm
Efficiency (max.)	88%
Height	12.7mm
Input voltage (max.)	160V DC
Insulation voltage	3000V DC
Length	31.8mm
Max. output current	666mA
Min. input voltage	43V DC
Misc Attribute	RSDW10H-15
No. of outputs	1
Operating temperature (max.)	+85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	666mA
Output voltage (max.)	15V DC
Power	10W
PSU features	DC-to-DC converter
RoHS-compliant	Yes
Weight	16g
Width	20.3mm
