Mean Well RDDW08G-05 DC/DC converter 800mA 8W 2 outputs 1pc

Mean Well
Standard range
Order Code:

05-1427

Brand: Mean Well MPN: RDDW08G-05
Qty Unit Price (Ex VAT)
1+ £16.48
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well RDDW08G-05 is a DC/DC converter module with dual outputs, providing a total power of 8 W and a current capacity of 800 mA. It is designed for applications requiring voltage conversion and electrical isolation in a compact package. Typical uses include powering electronic devices from a DC power source and managing power in embedded systems.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 83%
Height 10.2mm
Input voltage (max.) 75V DC
Insulation voltage 1500V DC
Length 31.8mm
Max. output current 800mA
Min. input voltage 18V DC
Misc Attribute RDDW08G-05
No. of outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 800mA
Power 8W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 18.4g
Width 20.3mm
