Mean Well PWM-60-12DA LED driver 60W 12V DALI dimmable outdoor rated IP67

The Mean Well PWM-60-12DA is a 60-watt LED driver that outputs 12 V DC at 5 A, making it suitable for a variety of LED lighting applications. It is DALI dimmable and features surge protection, making it ideal for both outdoor use and installation on furniture or flammable surfaces. This LED driver is designed to power LED strips and other LED devices, providing reliable performance with overvoltage protection.

Type	LED driver
Output Voltage	12V DC
Max Output Power	60W
Output Current	5A
Colour	Anthracite
Connection	Open end cable
Dimensions	(L x W x H) 150 x 53 x 35 mm
Height	35mm
IP Rating	IP67
Length	150mm
Max. output current	5A
Max. temperature	+85°C
Min. temperature	-40°C
Misc Attribute 1	Constant voltage
Misc Attribute 2	Synchronised
Number of Inputs	1
Number of Outputs	1
Protection Class	II
Test mark	CE, CB, UL, SELV, ENEC,mm
Weight	490g
Width	53mm
