Mean Well PWM-60-12DA LED driver 60W 12V DALI dimmable outdoor rated IP67

Mean Well
Order Code:

05-1402

Brand: Mean Well MPN: PWM-60-12DA EAN-13: 4021087052252
Qty Unit Price (Ex VAT)
1+ £41.27
5+ £39.74
10+ £38.14
30+ £36.44
60+ £34.88
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
107 in stock, despatched in 4 working days

The Mean Well PWM-60-12DA is a 60-watt LED driver that outputs 12 V DC at 5 A, making it suitable for a variety of LED lighting applications. It is DALI dimmable and features surge protection, making it ideal for both outdoor use and installation on furniture or flammable surfaces. This LED driver is designed to power LED strips and other LED devices, providing reliable performance with overvoltage protection.
Type LED driver
Connection Open end cable
Dim (L x W x H) 150 x 53 x 35 mm
Factory colour Anthracite
Height 35mm
IP Rating IP67
Length 150mm
Max. output current 5A
Max. power 60W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5A
Output voltage (max.) 12V DC
Power range 60 W (max)
Protection Class II
Test mark CE, CB, UL, SELV, ENEC, MM
Width 53mm
