Mean Well PWM-120-24DA PWM-120 LED driver 120W 24V DC dimmable DALI IP67

Mean Well
Order Code:

05-1386

Brand: Mean Well MPN: PWM-120-24DA EAN-13: 4021087042314
Qty Unit Price (Ex VAT)
1+ £55.23
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
49 in stock, despatched in 4 working days

The Mean Well PWM-120-24DA LED driver provides a constant voltage of 24 V DC, with a power rating of 120 W and a current rating of 5 A, making it suitable for dimmable LED applications. It features a DALI interface, PFC circuit, and surge protection, ensuring safe and efficient operation on flammable surfaces and furniture. This driver is ideal for outdoor use, making it a reliable choice for lighting installations needing robust voltage control.
Type LED driver
Connection Open end cable
Dim (L x W x H) 191 x 63 x 37.5 mm
Factory colour Anthracite
Height 37.5mm
IP Rating IP67
Length 191mm
Max. output current 5A
Max. power 120W
Max. temperature 90°C
Min. temperature -40°C
Misc Attribute Constant voltage
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5A
Output voltage (max.) 24V DC
Power range 120 W (max)
Protection Class II
Width 63mm
