Mean Well PSPA-1000-12 SMPSU 12V DC 80A 960W single piece

Mean Well
Order Code:

05-1371

Brand: Mean Well MPN: PSPA-1000-12 EAN-13: 4021087048743
Qty Unit Price (Ex VAT)
1+ £219.70
5+ £213.11
10+ £206.51
25+ £199.92
50+ £193.33
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/04/2026

The Mean Well PSPA-1000-12 is a switched-mode power supply unit (SMPSU) featuring a 12 V DC output and an 80 A current capacity, delivering up to 960 W of power. It is equipped with screw terminal connections for ease of installation in various industrial and commercial electronic systems. This PSU is suitable for applications requiring reliable high-power DC outputs, such as telecommunications, automation equipment, and large-scale LED displays.
Output Voltage 12V DC
Output Current 80A
Power Rating 960W
Number of Outputs 1
Input Voltage 180-264VAC
Connection Screw terminal
Dimensions (L x W x H) 170 x 120 x 93 mm
Height 93mm
Length 170mm
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 2743000h
Operating temperature (max.) +70°C
Operating temperature (min.) -20°C
PFC Yes
PSU features Adjustable voltage output
Type SMPSU
Width 120mm
