Mean Well MPM-05-3.3 MPM series ac/dc psu 3.3V 1.25A 4.1W for medical use

Mean Well
Standard range
Order Code:

05-1163

Brand: Mean Well MPN: MPM-05-3.3
Qty Unit Price (Ex VAT)
1+ £13.22
5+ £12.83
10+ £12.43
25+ £11.91
50+ £11.52
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well MPM-05-3.3 is an AC/DC power supply unit designed for mounting on a printed circuit board, delivering a stable output of 3.3 V DC at 1.25 A with a total power output of 4.1 W. It's ideal for compact electronic applications requiring reliable power in a small form factor. Typical applications include powering microcontrollers, sensors, and other low-voltage electronic components.
Type AC/DC PSU (print)
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 45.7 x 25.4 x 21.5 mm
Efficiency to 74%
Height 21.5mm
Input voltage (max.) 264V AC
Length 45.7mm
Max. output current 1.25A
Min. input voltage 80V AC
Misc Attribute 1 MPM-05-3.3
Misc Attribute 2 Pulsed
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.25A
Output current 1 1.25A
Output voltage (max.) 3.3V DC
Output voltage 1 3.3V DC
Power 4.1W
Protection class II
Residual ripple 100 mVpp
Tolerance (output voltage) 2.5%
Weight 35g
Width 25.4mm
