Mean Well MDR-40-48 DIN PSU 48V 0.83A 40W overload protection LED display

The Mean Well MDR-40-48 is a rail-mounted power supply unit (PSU) designed for DIN rail applications and provides a 48 V DC output with a current rating of 0.83 A and a total power output of 40 W. This enclosed design PSU features a single output and uses screw terminals for connections, making it ideal for industrial power supply applications. Typical uses for this power supply include powering industrial equipment and systems where reliable and efficient power delivery is essential.

Type	Rail mounted PSU (DIN)
Output Voltage	48 V/DC
Connection	Screw terminal
Dim	(L x W x H) 40.00 x 90.00 x 100.00 mm
Height	100.00mm
Input voltage (max.)	264V AC
Length	40.00mm
Max. output current	0.83A
Min. input voltage	90V AC
Misc Attribute 1	Synchronised
Number of Inputs	1
Number of Outputs	1
Output current (details)	0.83 A
Output current (max.) - rounded	830mA
Output voltage (max.)	48V DC
Output voltage (nominal)	48V DC
Power	40W
Width	90.00mm
