Mean Well LRS-75-15 SMPSU 15V 5A 75W low-profile EN60335-1 compliant

Mean Well
Order Code:

05-1087

Brand: Mean Well MPN: LRS-75-15 EAN-13: 4021087027656
Qty Unit Price (Ex VAT)
1+ £14.01
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well LRS-75-15 by Mean Well is a printed circuit board power supply unit with a 15 V DC output, 5 A current rating, and 75 W power capacity. This SMPSU is equipped with solder lugs for PCB mounting. It is typically used in a variety of electronic applications that require reliable power conversion and distribution.
Output Voltage 15V DC
Dim (L x W x H) 105 x 100 x 40 mm
Height 40mm
Input voltage (max.) 264V AC
Inputs 1
Length 105mm
Max. output current 5A
Max. power 75W
Min. input voltage 85V AC
Misc Attribute 1 Synchronised
Misc Attribute 3 closed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5A
Output voltage (max.) 15V DC
Power 75W
Type SMPSU
Width 100mm
