Mean Well LPF-25-12 LED driver 25W 2.1A 6.6-12V IP67 PFC surge protect

Mean Well
Order Code:

05-1024

Brand: Mean Well MPN: LPF-25-12 EAN-13: 4021087007825
Qty Unit Price (Ex VAT)
1+ £20.08
5+ £19.09
10+ £18.40
25+ £17.89
50+ £16.98
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well LPF-25-12 is an LED driver providing constant current with a power rating of 25.2 W and a current output of 2.1 A within a voltage range of 6.6 to 12 V DC. It features a power factor correction circuit and surge protection, making it suitable for use in LED strip lighting applications. This non-dimmable transformer is typically used for powering LED strip installations.
Type LED driver
Connection Open end cable
Dim (L x W x H) 148.00 x 40.00 x 32.00 mm
Height 32.00mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 148.00mm
Max. output current 2.1A
Max. power 25.2W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 2.1A
Output voltage (max.) 12V DC
Output voltage (min.) 6.6V DC
Power range 25.2 W (max)
Protection Class II
Width 40.00mm
