Mean Well IRM-02-15 series AC/DC PSU 15V 133mA low power compact size

Mean Well
Order Code:

05-0916

Brand: Mean Well MPN: IRM-02-15 EAN-13: 4021087034722
Qty Unit Price (Ex VAT)
1+ £5.79
5+ £5.61
10+ £5.43
25+ £5.35
50+ £5.27
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well IRM-02-15 is a PCB mount AC/DC power supply unit providing 15 V DC at 133 mA with a power rating of 2 W. It features solder lugs for easy connection to printed circuit boards. This compact power supply is suitable for applications in consumer electronics and small device equipping.
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 75%
Height 15mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 133mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 133mA
Output voltage (max.) 15V DC
Power 2W
Protection Class II
Residual ripple 200 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
