Mean Well IRM-01-3.3S AC/DC PSU 3.3V DC 300mA compact low power

Mean Well
Order Code:

05-0910

Brand: Mean Well MPN: IRM-01-3.3S EAN-13: 4021087034791
Qty Unit Price (Ex VAT)
1+ £5.58
5+ £5.42
10+ £5.25
25+ £5.08
50+ £5.03
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
13 in stock, despatched in 4 working days

The Mean Well IRM-01-3.3S is a PCB mount AC/DC power supply unit providing 3.3 V DC at 300 mA, with a power rating of 1 W. It features surface-mount design and solder lugs for easy integration into circuit boards. This compact PSU is suitable for small electronic devices and applications that require reliable low-power DC supply.
Connection SMD
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 16 mm
Efficiency to 66%
Height 16mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 300mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 300mA
Output voltage (max.) 3.3V DC
Power 1W
Protection Class II
Residual ripple 150 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
