Mean Well HRP-200-24 SMPSU 24V 8.4A 201W Enclosed PFC protections

Image Representative of Range

Mean Well HRP-200-24 SMPSU 24V 8.4A 201W Enclosed PFC protections

Mean Well
Order Code:

05-0883

Brand: Mean Well MPN: HRP-200-24 EAN-13: 4021087017077
Qty Unit Price (Ex VAT)
1+ £54.13
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HRP-200-24 is a 201 W switching mode power supply unit (SMPSU) designed for PCB mount applications. It delivers a stable 24 V DC output with a current rating of 8.4 A, making it suitable for industrial and electronic device power needs. This power supply is often used for equipping printed circuit boards and features screw terminals for easy installation.
Output Voltage 24 VDC
Connection Screw terminal
Dim (L x W x H) 199.00 x 98.00 x 38.00 mm
Height 38.00mm
Input voltage (max.) 264V AC
Length 199.00mm
Max. output current 8.4A
Min. input voltage 90V AC
Misc Attribute 1 Synchronised
Misc Attribute 3 closed
Number of Inputs 1
Number of Outputs 1
Output current (details) 8.4 A
Output current (max.) - rounded 8.4A
Output voltage (max.) 24V DC
Power 201W
Type SMPSU
Width 98.00mm
