Mean Well HLG-480H-24B LED driver 480 W dimmable 24 V IP67 outdoor use

Mean Well
Order Code:

05-0855

Brand: Mean Well MPN: HLG-480H-24B EAN-13: 4021087038850
Qty Unit Price (Ex VAT)
1+ £204.36
5+ £202.82
10+ £201.28
25+ £199.75
50+ £198.22
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched same dayBack-order availability date - 19/12/2025

The Mean Well HLG-480H-24B is an LED driver with a constant voltage and current of 480 watts and 20 amperes, delivering 12 to 24 V DC. It features a 3-in-1 dimming function, surge protection, and a PFC circuit, making it suitable for outdoor lighting applications. This unit is ideal for powering LED strips or lighting systems requiring reliable dimming and overvoltage protection.
Type LED driver
Output Voltage 12V DC
Max Output Power 480W
Output Current 20A
Input Voltage 305V AC
Colour Aluminium
Connection Open end cable
Dimensions (L x W x H) 244.2 x 68 x 38.3 mm
Height 38.3mm
IP Rating IP67
Length 244.2mm
Max. output current 20A
Max. temperature +90°C
Min. input voltage 90V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Protection Class I
Width 68mm
